TECHNICAL DATA:
- transferring: single-sided
- heating drum: oil
- heating drum diameter: 240 mm
- heating drum width: 505 mm
- width of transmission belt: 500 mm
- maximum speed: 3000 mm/min
- speed for 30 s heating: 1140 mm/min
- speed for 40 s heating: 855 mm/min
- maximum material thickness: 3 mm
- -temperature control : from 1⁰C up to 220⁰C
- maximum power consumption: 3.55 kW
- power supply: 230 V
- weight: 280 kg
- dimensions: D=800 mm with table , W=1400 mm , S=1055 mm
- requirement for compressed air: approx. 1.5 l/cycle -pneumatic tension control
- pneumatic control of transmission belt tension
- electronic shaft speed control
PRODUCTIVITY:
- 1500 pieces of lanyards 15 mm/1 h wide, printed on one side i.e. 750 pieces of finished lanyards 15 mm/1 h wide
SECURITIES:
- 2 x E-stop
- automatic shutdown of the machine in case of drive control errors and power voltage drop
OTHER:
- special equipment (so-called portable table) that allows transferring on tapes widths: 5 mm, 10 mm, 15 mm, 20 mm, 25 mm, e.g.: advertising lanyards, clothing labels, elastic suspenders, scarves, shoe laces etc.
- 2 rollers with carrier medium
- 3 automatic paper rollers
- 2 rollers with protective paper
- crank (in case of power failure)
- recommended width of sublimation paper - 42 cm
- CE declarations
